2inch Galvanized Welded Mesh Panel Construction Metal Reinforcing Sheet

Ask Lasest Price
Brand Name :	QIJIE
Model Number :	QJ-WMP-01
Certification :	SGS, ISO
Price :	USD 0.5-5/M2
Payment Terms :	TT,LC,
Supply Ability :	1000 square meters per day
Delivery Time :	10-15 working days

Add to Cart

Product Details
Company Profile

2inch Galvanized Welded Mesh Panel Construction Metal Reinforcing Sheet

2inch Galvanized Construction Metal Reinforcing Welded Wire Mesh Sheet

Welded wire mesh, or welded wire fabric, or "weldmesh" is an electric fusion welded prefabricated joined grid consisting of a series of parallel longitudinal wires with accurate spacing welded to cross wires at the required spacing.
Machines used to produce the mesh must be with precise dimensional control. The product in considerable savings in time. labor and money.

Till now, we have 8 sets of large-scale automatic multiple spot welding machine, 7 stes of medium -sized multiple spot welding machine.
As for the production ability, we can produce 150-300 tons of welded wire mesh per month.(about 7-15 40' high containers)

As a leading welded wire mesh supplier and manufacturer,we offers a full range of welded wire mesh for various applications. We supply the mesh from 1/2" to 6", customer requst can be customized .Welded wire mesh is generally constructed in rolls or flat panels designed by customers. Green plastic coated is widely used for fence and breeding .Custom wire openings available upon request.

Electro galvanized welded wire mesh
This type of welded wire mesh is designed for building fencing and for other infrastruc- tural purposes. lt is a type of corrosion resis- tantwire mesh that mainly used in structural building. lt is also available in different forms like rolls and panelsfor industrial uses.

[ Specifications ]

welded wire mesh rolls
Opening	Wire diameter	Available Width
1/4" x 1/4"	0.45mm-0.7mm	300mm-1830mm
3/4" x 3/4"	0.7mm-2.0mm	300mm-1830mm
3/8" x 3/8"	0.7mm-1.1mm	300mm-1830mm
5/8" x 5/8"	0.8mm-1.2mm	300mm-1830mm
1/2" x 1/2"	0.45mm-1.6 mm	300mm-1830mm
1" x 1"	0.7mm-3.0mm	300mm-2000mm
1" x 1/2"	0.8mm-1.6mm	300mm-1828mm
1-1/2" x 1-1/2"	0.7mm-3.5mm	300mm-1828mm
1" x 2"	1.6mm-2.1mm	300mm-1828mm
2" x 2"	0.7mm-4.0mm	300mm-2500mm
2" x 3"	1.5mm-3.5mm	300mm-2000mm
2" x 4"	2.0mm-4.0mm	300mm-1828mm
3" x 3"	1.0mm-4.5mm	300mm-2500mm
3" x 4"	1.5mm-4.5mm	300mm-2000mm
4" x 4"	1.0mm-4.5mm	300mm-2500mm
5" x 5"	2.5mm-4.5mm	300mm-2500mm
6" x 6"	2.5mm-4.5mm	300mm-2500mm

Welded Wire Mesh Panels
Opening	Wire diameter	Available width
1/2" x 1/2"	0.45mm-2.0mm	100mm-1830mm
1" x 1"	0.7mm-3.5mm	100mm-2000mm
1" x1/4"	0.45mm-4.0mm	100mm-2000mm
1x 1/2"	0.45mm-4.0mm	100mm-3600mm
2" x 2"	0.7mm-6.0mm	100mm-3600mm
3" x 3"	1.0mm-7.0mm	100mm-3600mm
4" x 4"	1.0mm-8.0mm	100mm-3600mm
5" x 5"	2.5mm-9.0mm	100mm-3600mm
6" x 6"	2.5mm-10.0mm	100mm-3600mm

Roll or panel length can be negotiated, welcome to contact us for further information.
[ Quality Standard ]

Our products can meet below quality standard:
[ JG/T114-1997 ] National Standard
[ BS4483 ] British Standard
[ DIN488 ] German Standard
[ SIA16211 S550 ] Swiss Fabric Standard
[ NFA35-016 ] Franch Fabric Standard
[ onORM B4200/7 ] Australian Fabric Standard

welded mesh sheet
